Products - Beam & Joists
(nailing strips are plastic - wood available upon request)
|
Standard Lengths/Weights - Hi-Lite
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
44
|
20
|
|
12
|
3.7
|
50
|
23
|
|
14
|
4.3
|
59
|
27
|
|
16
|
4.9
|
67
|
30
|
|
18
|
5.5
|
76
|
34
|
|
21
|
6.4
|
88
|
40
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
The 6½" Hi-Lite Style HL-Beam is a heavier beam than the A-Beam. It can bear somewhat more weight in use than the A-Beam. It also is designed with curls at the ends of all flanges to ensure proper gripping of clamps. The curls also act to provide a stronger flange edge, less apt to be damaged in use and thus providing greater longevity in the field.
As are all GATEWAY beams and stringers, the Hi-Lite Style Beam contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The Hi-Lite Style Beam has the standard T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
As are all GATEWAY beams and stringers, the Hi-Lite Style Beam contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The Hi-Lite Style Beam has the standard T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
|
Physical Specifications - Hi-Lite
|
||
|
Overall Height
|
6.5 inches
|
165 mm
|
|
Width, Base
|
4.8 inches
|
122 mm
|
|
Width, Top
|
3.3 inches
|
84 mm
|
|
Cross Sectional Area (w/o nailer)
|
2.8 inches*2
|
1806 mm*2
|
|
Nominal Weight (w/o nailer)
|
3.4 lbs/foot
|
5.1 kg/m
|
|
Nominal Weight (with nailer)
|
4.2 lbs/foot
|
6.3 kg/m
|
|
Standard Lengths/Weights - 6.5" A-Beam
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
43
|
19
|
|
12
|
3.7
|
49
|
22
|
|
14
|
4.3
|
57
|
25
|
|
16
|
4.9
|
66
|
29
|
|
18
|
5.5
|
74
|
33
|
|
21
|
6.4
|
86
|
38
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
Load Charts Available Upon Request
(330) 633-3700
Load Charts Available Upon Request
Load Charts Available Upon Request
© 2010 Construction Components Inc. dba Gateway Industries
1236 Brittain Road
Akron, Ohio 44310
Akron, Ohio 44310
Phone (330) 633 - 3700
Fax (330) 633 - 3716
Fax (330) 633 - 3716
All Gateway Industries Joists, Beams, Stringers are compatible with all major aluminum shoring systems including Aluma Systems' Aluma Beam, Aluma Stringer, Aluma Strongback, and Jasco's Hi-Lite Beam, Hi-Lite Stringer, and Patent Construction' (Harsco) Patent Joist, Patent Stringer, and Symons Joist, Symons Beam, and Safway Joist, Safway Stringer, and Waco Scaffolding Beam, Waco Stringer, etc....
QUICK
LINKS
LINKS
Serving the Concrete Construction
Industry For Over 30 Years
Industry For Over 30 Years
The 6½" aluma style aluminum A-Beam - 4" Base is a profile with a narrow 4" bottom flange, perfect for doubling up in 8" shoring-post saddles for extra stregnth.
The beauty of this engineered profile is that it is not simply an A-Beam clone where 1" of bottom flange (and strength) is missing. The aluminum removed from the bottom flange width has been engineered back into the profile so that this shape CONFORMS to the industry standard, 6.5" A-Beam load chart. This product thus weighs the same as the standard A-Beam and is priced similarly.
And too, for the sake of positive A-Clamping, the bottom flange tips have been created to mate perfectly with the standard A-Clamp. These have the side benefit of providing a particularly strong and damage resistant flange.
As with the standard A-Beam, this product contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The A-Beam - 4" Base has a T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the easy-to-use self-locking A-Bolt.
The beauty of this engineered profile is that it is not simply an A-Beam clone where 1" of bottom flange (and strength) is missing. The aluminum removed from the bottom flange width has been engineered back into the profile so that this shape CONFORMS to the industry standard, 6.5" A-Beam load chart. This product thus weighs the same as the standard A-Beam and is priced similarly.
And too, for the sake of positive A-Clamping, the bottom flange tips have been created to mate perfectly with the standard A-Clamp. These have the side benefit of providing a particularly strong and damage resistant flange.
As with the standard A-Beam, this product contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The A-Beam - 4" Base has a T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the easy-to-use self-locking A-Bolt.
The 6½" aluma style A-Beam - 4" Flat Base is also a profile with a narrow 4" flat-bottom flange, perfect for doubling up in 8" shoring-post saddles for extra stregnth.
And again, the beauty of this engineered profile is that it is not simply an A-Beam clone where 1" of bottom flange (and strength) is missing. The aluminum removed from the bottom flange width has been engineered back into the profile so that this shape CONFORMS to the industry standard, 6.5" A-Beam load chart. This product thus also weighs the same as the standard A-Beam and is also priced similarly.
The bottom flange has been left in its original geometry should the user wish to affix the flange by means other than standard clamping.
As with the standard A-Beam, this product contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The A-Beam - 4" Base has a T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the easy-to-use self-locking A-Bolt.
And again, the beauty of this engineered profile is that it is not simply an A-Beam clone where 1" of bottom flange (and strength) is missing. The aluminum removed from the bottom flange width has been engineered back into the profile so that this shape CONFORMS to the industry standard, 6.5" A-Beam load chart. This product thus also weighs the same as the standard A-Beam and is also priced similarly.
The bottom flange has been left in its original geometry should the user wish to affix the flange by means other than standard clamping.
As with the standard A-Beam, this product contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The A-Beam - 4" Base has a T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the easy-to-use self-locking A-Bolt.
Load Charts Available Upon Request
|
Physical Specifications - 6.5" A-Beam - 4" Base
|
||
|
Overall Height
|
6.5 inches
|
165 mm
|
|
Width, Base
|
5.0 inches
|
127 mm
|
|
Width, Top
|
3.2 inches
|
81 mm
|
|
Cross Sectional Area (w/o nailer)
|
2.7 inches*2
|
1742 mm*2
|
|
Nominal Weight (w/o nailer)
|
3.2 lbs/foot
|
4.8 kg/m
|
|
Nominal Weight (with nailer)
|
4.1 lbs/foot
|
6.3 kg/m
|
|
Standard Lengths/Weights - 6.5" A-Beam - 4" Base
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
43
|
19
|
|
12
|
3.7
|
49
|
22
|
|
14
|
4.3
|
57
|
25
|
|
16
|
4.9
|
66
|
29
|
|
18
|
5.5
|
74
|
33
|
|
21
|
6.4
|
86
|
38
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
|
Physical Specifications - 6.5" A-Beam - 4" Flat Base
|
||
|
Overall Height
|
6.5 inches
|
165 mm
|
|
Width, Base
|
5.0 inches
|
127 mm
|
|
Width, Top
|
3.2 inches
|
81 mm
|
|
Cross Sectional Area (w/o nailer)
|
2.7 inches*2
|
1742 mm*2
|
|
Nominal Weight (w/o nailer)
|
3.2 lbs/foot
|
4.8 kg/m
|
|
Nominal Weight (with nailer)
|
4.1 lbs/foot
|
6.3 kg/m
|
|
Standard Lengths/Weights - 6.5" A-Beam - 4" Flat Base
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
43
|
19
|
|
12
|
3.7
|
49
|
22
|
|
14
|
4.3
|
57
|
25
|
|
16
|
4.9
|
66
|
29
|
|
18
|
5.5
|
74
|
33
|
|
21
|
6.4
|
86
|
38
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
|
Physical Specifications - 6.5" A-Beam
|
||
|
Overall Height
|
6.5 inches
|
165 mm
|
|
Width, Base
|
5.0 inches
|
127 mm
|
|
Width, Top
|
3.2 inches
|
81 mm
|
|
Cross Sectional Area (w/o nailer)
|
2.7 inches*2
|
1742 mm*2
|
|
Nominal Weight (w/o nailer)
|
3.2 lbs/foot
|
4.8 kg/m
|
|
Nominal Weight (with nailer)
|
4.1 lbs/foot
|
6.3 kg/m
|
The 6½" aluma style aluminum A-Beam has been the workhorse of the industry for decades. Its strength and lightweight properties provide an optimal working combination. Aluminum minimizes the number of total horizontal and vertical members required on the job, compared to wood. Since it is lightweight compared to steel, the contractor realizes labor productivity through ease of use.
The A-Beam contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The A-Beam has a T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the easy-to-use self-locking A-Bolt.
The A-Beam contains a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
The A-Beam has a T-Head Bolt slot in its base for fastening stringers, strongbacks or I-Beams with the easy-to-use self-locking A-Bolt.
