Products - Aluminum Stringers
(nailing strips are plastic - wood available upon request)
The 7½" aluma style aluminum A-Stringer is used in combination with 6½" Beam. The A-Stringer is lighter weight than our Heavy, 4" Flanged Stringer, providing stringer class strength at a cost effective price.
The A-Stringer is easily clamped to the 6½" Beam, usually via an A-Clamp or W-Clamp.
As are all GATEWAY beams and stringers, the A-Stringer contain a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
As in all of our stringers and beams, the A-Stringer has the standard T-Head Bolt slot in its base for fastening other stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
The A-Stringer is easily clamped to the 6½" Beam, usually via an A-Clamp or W-Clamp.
As are all GATEWAY beams and stringers, the A-Stringer contain a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
As in all of our stringers and beams, the A-Stringer has the standard T-Head Bolt slot in its base for fastening other stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
|
Physical Specifications - A-Stringer
|
||
|
Overall Height
|
7.5 inches
|
191 mm
|
|
Width, Base
|
5.0 inches
|
127 mm
|
|
Width, Top
|
3.9 inches
|
100 mm
|
|
Cross Sectional Area (w/o nailer)
|
4.0 inches*2
|
2581 mm*2
|
|
Nominal Weight (w/o nailer)
|
4.8 lbs/foot
|
7.2 kg/m
|
|
Nominal Weight (with nailer)
|
5.8 lbs/foot
|
8.7 kg/m
|
|
Standard Lengths/Weights - A-Stringer
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
61
|
28
|
|
12
|
3.7
|
70
|
32
|
|
14
|
4.3
|
81
|
37
|
|
16
|
4.9
|
93
|
42
|
|
18
|
5.5
|
104
|
47
|
|
21
|
6.4
|
122
|
55
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
The 7½" Waco style Heavy Stringer, 4" Flanged Base Beam is used in combination with the 6½" Beam. This Stringer Beam is one of the beefiest in the industry with an unusually high web thickness. Its lower flange is 4" wide, allowing these to be doubled in an 8" saddle for particularly heavy jobs.
This Stringer Beam is easily clamped to 6½" Beam usually via an A-Clamp or W-Clamp.
As are all GATEWAY beams and stringers, our stringer products contain a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
As in all of our stringers and beams, this product has the standard T-Head Bolt slot in it's base for fastening other stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
This Stringer Beam is easily clamped to 6½" Beam usually via an A-Clamp or W-Clamp.
As are all GATEWAY beams and stringers, our stringer products contain a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
As in all of our stringers and beams, this product has the standard T-Head Bolt slot in it's base for fastening other stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
|
Physical Specifications - Heavy-Stringer
|
||
|
Overall Height
|
7.5 inches
|
191 mm
|
|
Width, Base
|
4.0 inches
|
102 mm
|
|
Width, Top
|
3.1 inches
|
79 mm
|
|
Cross Sectional Area (w/o nailer)
|
4.3 inches*2
|
2774 mm*2
|
|
Nominal Weight (w/o nailer)
|
5.2 lbs/foot
|
7.8 kg/m
|
|
Nominal Weight (with nailer)
|
6.2 lbs/foot
|
9.3 kg/m
|
|
Standard Lengths/Weights - Heavy-Stringer
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
65
|
30
|
|
12
|
3.7
|
74
|
34
|
|
14
|
4.3
|
87
|
40
|
|
16
|
4.9
|
99
|
45
|
|
18
|
5.5
|
112
|
51
|
|
21
|
6.4
|
130
|
59
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
Load Charts Available Upon Request
Load Charts Available Upon Request
© 2010 Construction Components Inc. dba Gateway Industries
1236 Brittain Road
Akron, Ohio 44310
Akron, Ohio 44310
Phone (330) 633 - 3700
Fax (330) 633 - 3716
Fax (330) 633 - 3716
All Gateway Industries Joists, Beams, Stringers are compatible with all major aluminum shoring systems including Aluma Systems' Aluma Beam, Aluma Stringer, Aluma Strongback, and Jasco's Hi-Lite Beam, Hi-Lite Stringer, and Patent Construction' (Harsco) Patent Joist, Patent Stringer, and Symons Joist, Symons Beam, and Safway Joist, Safway Stringer, and Waco Scaffolding Beam, Waco Stringer, etc....
The 7¼ " Hi-Lite Style Double Ended Stringer is used where there is no need for a nailing strip and where the strength of a stringer is required. Both ends of this product are capable of being affixed to other shoring members via the standard T-Head Bolt available in the A-Bolt Assembly and both A-Clamps and W-Clamps.
Like the HL-Beam, it also is designed with curls at the ends of all flanges to ensure proper gripping of clamps. The curls also act to provide a stronger flange edge, less apt to be damaged in use and thus providing greater longevity in the field.
Like the HL-Beam, it also is designed with curls at the ends of all flanges to ensure proper gripping of clamps. The curls also act to provide a stronger flange edge, less apt to be damaged in use and thus providing greater longevity in the field.
|
Physical Specifications - HL Stringer
|
||
|
Overall Height
|
7.25 inches
|
184 mm
|
|
Width, Bottom
|
3.9 inches
|
100 mm
|
|
Width, Top
|
3.9 inches
|
100 mm
|
|
Cross Sectional Area
|
3.7 inches*2
|
2355 mm*2
|
|
Nominal Weight
|
4.4 lbs/foot
|
6.6 kg/m
|
Load Charts Available Upon Request
|
Standard Lengths/Weights - HL Stringer
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
|
Weight (kg)
|
|
10.5
|
3.2
|
46
|
21
|
|
12
|
3.7
|
53
|
24
|
|
14
|
4.3
|
62
|
28
|
|
16
|
4.9
|
70
|
32
|
|
18
|
5.5
|
79
|
36
|
|
21
|
6.4
|
92
|
42
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
QUICK
LINKS
LINKS
Serving the Concrete Construction
Industry For Over 30 Years
Industry For Over 30 Years
(330) 633-3700
The 7½" aluma style aluminum A-Stringer - 4" Base is used in combination with 6½" Beam. The A-Stringer - 4" Base is lighter weight than our Heavy, 4" Bottom Flanged Waco style stringer, providing stringer class strength at a cost effective price.
The beauty of this engineered profile is that it is not simply an A-Stringer clone where 1" of bottom flange (and strength) is missing. The aluminum removed from the bottom flange width has been engineered back into the profile so that this shape CONFORMS to the industry standard, 7.5" A-Stringer load chart. This product thus weighs the same as the standard A-Stringer and is priced similarly.
And too, for the sake of positive A-Clamping, the bottom flange tips have been created to mate perfectly with the standard A-Clamp. These have the side benefit of providing a particularly strong and damage resistant flange.
The A-Stringer is easily clamped to the 6½" Beam, usually via an A-Clamp or W-Clamp.
As are all GATEWAY beams and stringers, the A-Stringer contain a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
As in all of our stringers and beams, the A-Stringer has the standard T-Head Bolt slot in its base for fastening other stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
The beauty of this engineered profile is that it is not simply an A-Stringer clone where 1" of bottom flange (and strength) is missing. The aluminum removed from the bottom flange width has been engineered back into the profile so that this shape CONFORMS to the industry standard, 7.5" A-Stringer load chart. This product thus weighs the same as the standard A-Stringer and is priced similarly.
And too, for the sake of positive A-Clamping, the bottom flange tips have been created to mate perfectly with the standard A-Clamp. These have the side benefit of providing a particularly strong and damage resistant flange.
The A-Stringer is easily clamped to the 6½" Beam, usually via an A-Clamp or W-Clamp.
As are all GATEWAY beams and stringers, the A-Stringer contain a 2" x 2" plastic nailer strip which is formulated to provide nail gripping properties comparable to wood, and will not become soft in hot weather, nor brittle, nor crack in extreme cold. Plastic nailers are much more durable than wood and will withstand repeated use as plastic is apt to self-heal upon fastener removal.
As in all of our stringers and beams, the A-Stringer has the standard T-Head Bolt slot in its base for fastening other stringers, strongbacks or I-Beams with the standard easy-to-use self-locking A-Bolt.
|
Physical Specifications - A-Stringer
|
||
|
Overall Height
|
7.5 inches
|
191 mm
|
|
Width, Base
|
5.0 inches
|
127 mm
|
|
Width, Top
|
3.9 inches
|
100 mm
|
|
Cross Sectional Area (w/o nailer)
|
4.0 inches*2
|
2581 mm*2
|
|
Nominal Weight (w/o nailer)
|
4.8 lbs/foot
|
7.2 kg/m
|
|
Nominal Weight (with nailer)
|
5.8 lbs/foot
|
8.7 kg/m
|
|
Standard Lengths/Weights - A-Stringer
|
|||
|
Length (ft)
|
Length (m)
|
Weight (lbs)
(with nailer) |
Weight (kg)
(with nailer) |
|
10.5
|
3.2
|
61
|
28
|
|
12
|
3.7
|
70
|
32
|
|
14
|
4.3
|
81
|
37
|
|
16
|
4.9
|
93
|
42
|
|
18
|
5.5
|
104
|
47
|
|
21
|
6.4
|
122
|
55
|
|
* Custom Lengths Available on a Per-Order Basis.
|
|||
Load Charts Available Upon Request
